A06B-6141
A06B-6141-H002#H580 αi SP 2.2
A06B-6141-H006#H580 αi SP 5.5
A06B-6141-H011#H580 αi SP 11
A06B-6141-H015#H580 αi SP 15
A06B-6141-H022#H580 αi SP 22
A06B-6141-H026#H580 αi SP 26
A06B-6141-H030#H580 αi SP 30
A06B-6141-H037#H580 αi SP 37
A06B-6141-H045#H580 αi SP 45
A06B-6141-H055#H580 αi SP 55
Spindle amplifier module (SPM)
The spindle amplifier module (SPM) is used to drive a spindle motor.
A SPM is selected according to the spindle motor connected to the SPM.
There are three types of spindle amplifier module, as follows:
<1> Spindle amplifier module (SPM) This module drives a spindle motor of
the 200-V input series.
<2> Spindle amplifier module (SPMC) This module drives the αCi series
spindle motor.
<3> Spindle amplifier module (SPM-HV) This module drives a spindle motor
of the 400V input series.
SPM - x HV i
(A) (B) (C)
(A) Model name:
SPM = Spindle amplifier module
SPMC= Spindle amplifier module applied to spindle αCi series
(B) Output: Numeric value representing the 30-minutes rating of a matching
standard motor (αi) in kW
(C) For an amplifier supporting 400-V input, "HV" is added.
