A06B-6090-H233 SVUC 2-12/12

Repair/ Return Option for 6090-H233 Available At $980.

Rated Input: 200~230 VAC 4.6A at 200V

Rated Output Current: L axis: 2.9A, L axis: 2.9A

Fanuc A06B-6090-H233 replaces A06B-6066-H233

A06B6090H233 B65192E Manual

Related technical information

Installation Guide

A06b-6090h233

A06B-6090-H233

A06B-6090-H233

A06B-6090-H233 Alarms Meaning and action to be taken

Alarm     Meaning
1            Over Voltage Alarm (HV)
2            Low Control Voltage Alarm (LV)
3            Low DC Link Voltage Alarm (LVDC)
4            Regenerative Control Circuit Alarm (DCSW)
5            Over Regenerative Discharge Alarm (DCOH)
7            Dynamic brake Circuit Failure Alarm (DBRLY)
8            L-Axis Over current Alarm (HCL)
9            M-Axis Over current Alarm (HCM)
8.           L-Axis IPM Alarm (IPML)
9.           M-Axis IPM Alarm (IPMM)
b            L & M Axes Over Current
b.           L & M Axes IPM Alarm
