Alarm List for A06B-6079-Hxxx A06B-6096-Hxxx A06B-6080-Hxxx

Alpha Series Servo Amplifier Modules are equipped with LEDs  to indicate alarm condition.

 FANUC SERVO AMPLIFIER MODULE ALARM CODES LIST

A06B6079Hxxx A06B-6096-Hxxx A06B-6080-Hxxx B65165E Manual

Related technical information

Alarms Meaning and action to be taken

Alarm     Meaning
1              Internal Fan Stopped (FAL)
2              Low control power voltage (LV5V)
5              Low DC link voltage (LVDC)
8              L-axis over-current (HCL)
9              M-axis over-current (HCM)
A              N-axis over-current (HCN)
b             L & M-axis over-current
C             M & N-axis over-current
d             L & N-axis over-current
E              L, M, N -axis over-current
8.             L-axis IPM alarm (IPML)
9.             M-axis IPM alarm (IPMM)
A.             N-axis IPM alarm (IPMN)
b.            L & M-axis IPM alarm
C.            M & N-axis IPM alarm
d.            L & N-axis IPM alarm
E.             L, M, N-axis IPM alarm
